🔍 What is the Model Context Protocol?

⚠️ IMPORTANT: Security & Limitations

Please read this section carefully before using PingOne MCP Server.

🔄 Data Flow & Privacy

When you make a request, the interaction happens directly between the LLM and the PingOne MCP tools - the client application is no longer in the middle. All data returned by these tools (including complete user profiles, group memberships, MFA devices, audit logs, etc.) is sent to and stored in the LLM's context during the entire transaction for that conversation.

Key Privacy Considerations:

• The LLM (Claude, GPT, etc.) receives and processes all PingOne data retrieved by the tools
• This data remains in the LLM's context for the duration of the conversation
• You must be comfortable with your PingOne user data being processed by the LLM provider's systems
• Before using these tools, ensure you're comfortable with PingOne data being sent to the AI model's servers

📊 Context Window Limitations

🚨 CRITICAL LIMITATION: Due to MCP design and LLM context window constraints, you can only effectively work with 70-90 users maximum per operation. This is not a technical limitation of PingOne APIs, but rather a fundamental constraint of how much data can fit in an LLM's context window.

Recommendation: Always limit user queries and avoid bulk operations.

Examples:

❌ Avoid these types of requests:

• "Get all users in our tenant and analyze their login patterns" (could be thousands of users)
• "Find all users without MFA and create a report" (potentially hundreds of users)
• "List all users in the Employee population" (likely exceeds context limits)

✅ Better approaches:

• "Get the 50 most recently created users in the Contractor population"
• "Find users with email domain @contractor.com, limit to first 30 results"
• "Show me users whose names start with 'John' in the Production environment"
• "Get audit activity for authentication failures in the last 24 hours"

Working Within Limits:

• Use SCIM filters to narrow results: enabled eq false and type eq "Employee"
• Use pagination limits: Never exceed 70-90 users in a single request
• Focus on specific populations or user attributes
• Use date filters for audit queries to limit scope

🚨 HTTP Transport Security Warning

The HTTP transport mode has significant security risks:

• It opens an unauthenticated HTTP server with full access to your PingOne tenant
• No authentication or authorization is provided
• Anyone who can reach the network port can issue commands to your PingOne environment

Best Practice: Only use the STDIO transport method (default mode) unless you have specific security controls in place and understand the risks.

🛠️ Available Tools

The PingOne MCP Server provides comprehensive identity management capabilities:

🏢 Environment Management

• list_configured_environments - START HERE - List all environments configured for this MCP server
• list_pingone_environments - List ALL environments in your PingOne organization
• get_pingone_environment - Get detailed environment information and configuration
• list_pingone_environment_resources - List applications and API resources in an environment
• get_pingone_environment_activity - Get audit logs and session activity with date filtering

👥 User Management

• list_pingone_users - Search users with advanced SCIM filtering (enabled, population, email domain, etc.)
• get_pingone_user - Get detailed user information including lifecycle status and MFA settings
• get_pingone_user_sessions - Get user login sessions with browser, device, and location details

🔐 MFA & Security

• list_pingone_user_mfa_devices - List all MFA devices for a user (SMS, TOTP, FIDO2, etc.)
• get_pingone_user_mfa_device - Get detailed MFA device information and status

👨‍👩‍👧‍👦 Population Management

• list_pingone_populations - List all populations (Employee, Contractor, Customer, etc.)
• get_pingone_population - Get population details and password policies

🏘️ Group Management

• list_pingone_groups - List groups with filtering by name, population, or description
• get_pingone_group - Get group details and metadata
• list_pingone_users_in_group - List all users who are members of a specific group
• list_pingone_users_in_multiple_groups - Find users who belong to ALL specified groups (intersection)
• get_pingone_user_group_memberships - Get all group memberships for a specific user

🕐 DateTime Utilities

• get_current_time - Get current UTC time with optional offset (e.g., "24 hours ago")
• parse_relative_time - Convert natural language to timestamps ("yesterday", "last week")
• create_date_range - Create date ranges for audit queries ("1 week ago" to "now")

Example Use Cases:

• Security Analysis: "Show me all failed authentication attempts from yesterday in Production"
• Compliance Auditing: "Find all users without MFA enrolled in the Employee population"
• User Support: "Get login sessions for user "
• Environment Management: "List all custom API resources in our Staging environment"
• Group Analysis: "Show me all members of the IT-Administrators group"

🚀 Quick Start

Prerequisites

✅ Python 3.12+ installed on your machine
✅ PingOne tenant with appropriate API access
✅ An MCP-compatible AI client (Claude Desktop, Microsoft Copilot Studio, etc.)

⚠️ Important Model Compatibility Note:
Not all AI models work with this MCP server. Testing has only been performed with:

• GPT-4.0
• Claude 3.5 Sonnet
• Google Gemini 2.0

You must use latest model versions that explicitly support tool calling/function calling capabilities.

🧠 Supported AI Providers

The PingOne MCP Server supports multiple AI providers through its flexible configuration system.

Currently Supported Providers:

Installation

# Clone the repository
git clone https://github.com/yourusername/pingone-mcp-server.git
cd pingone-mcp-server

# Create and activate a virtual environment
python -m venv venv
source venv/bin/activate  # On Windows use: venv\Scripts\activate

# Install dependencies
pip install -r requirements.txt

⚠️ NOTICE: If you clone this repository anew or pull updates, always make sure to re-run pip install -r requirements.txt to ensure all dependencies are up-to-date.

Configuration & Usage

Create a config file with your PingOne settings:

# Copy the sample config
cp .env.sample .env

# Edit the .env file with your settings
# Required: PingOne environment details and LLM settings

Sample .env configuration for Multi-Environment Setup:

# PingOne Organization Settings
PING_REGION=NA
PING_ORG_ID=your-organization-id

# Default Environment
PING_DEFAULT_ENV=Production

# Environment 1: Production
PING_ENV_1_NAME=Production
PING_ENV_1_ID=prod-environment-id
PING_ENV_1_CLIENT_ID=prod-client-id
PING_ENV_1_CLIENT_SECRET=prod-client-secret
PING_ENV_1_ALIASES=prod,production,live

# Environment 2: Staging
PING_ENV_2_NAME=Staging
PING_ENV_2_ID=staging-environment-id
PING_ENV_2_CLIENT_ID=staging-client-id
PING_ENV_2_CLIENT_SECRET=staging-client-secret
PING_ENV_2_ALIASES=stage,staging,test

# Environment 3: Development
PING_ENV_3_NAME=Development
PING_ENV_3_ID=dev-environment-id
PING_ENV_3_CLIENT_ID=dev-client-id
PING_ENV_3_CLIENT_SECRET=dev-client-secret
PING_ENV_3_ALIASES=dev,development,sandbox

# AI Provider Configuration (choose one)
AI_PROVIDER=openai
OPENAI_API_KEY=your-openai-api-key

# Optional: Logging
LOG_LEVEL=INFO

Supported Transports and Launching

The PingOne MCP Server supports multiple transport protocols:

1. Standard I/O (STDIO) - Recommended

• Security: ✅ Direct communication through standard input/output streams
• Use case: Ideal for desktop AI assistants like Claude Desktop
• Performance: ✅ Lightweight and efficient
• Visibility: ✅ Full tool call logging and transparency

Configuration for Claude Desktop (claude_desktop_config.json):

PING_REGION can be north_america, europe, asia_pacific

{
  "mcpServers": {
    "pingone-mcp-server": {
      "command": "/path/to/pingone-mcp-server/venv/python",
      "args": [
        "/path/to/pingone-mcp-server/main.py"
      ],
      "env": {
        "PING_REGION": "NA",
        "PING_ORG_ID": "your-organization-id",
        "PING_DEFAULT_ENV": "Production",
        "PING_ENV_1_NAME": "Production",
        "PING_ENV_1_ID": "prod-environment-id",
        "PING_ENV_1_CLIENT_ID": "prod-client-id",
        "PING_ENV_1_CLIENT_SECRET": "prod-client-secret",
        "PING_ENV_1_ALIASES": "prod,production,live",
        "PING_ENV_2_NAME": "Staging",
        "PING_ENV_2_ID": "staging-environment-id",
        "PING_ENV_2_CLIENT_ID": "staging-client-id",
        "PING_ENV_2_CLIENT_SECRET": "staging-client-secret",
        "PING_ENV_2_ALIASES": "stage,staging,test",
      }
    }
  }
}

Testing STDIO Transport:

cd clients
python pingone-mcp-client.py --server ../main.py

2. Streamable HTTP Transport - Modern & Recommended

Features: ✅ Real-time event streaming, session management, tool call visibility

Starting the HTTP Server:

# Start server
python main.py --http

# Server will start on http://localhost:3000/mcp

Testing HTTP Transport:

cd clients
python pingone-mcp-client.py --http http://localhost:3000/mcp

Features:

• ✅ Real-time tool visibility - See exactly which PingOne APIs are being called
• ✅ Session management - Maintains connection state
• ✅ Event streaming - Live progress updates during operations
• ✅ Better error handling - Detailed error responses
• ✅ Modern protocol - Based on latest MCP specifications

3. Interactive Client

For testing and development:

cd clients
python pingone-mcp-client.py --server ../main.py

# Or for HTTP transport:
python pingone-mcp-client.py --http http://localhost:3000/mcp

Client Features:

• 🔍 Tool call visibility: See exactly which tools are being called
• 💬 Interactive shell: Continuous query support
• 🛠️ Tool inspection: Use tools command to see available tools
• 🔧 Debug mode: Use debug on for detailed message exchanges
• 📊 Structured results: Clean JSON output formatting

Example Client Session:

PingOne MCP Client
Type 'exit' to quit
Type 'tools' to show available tools
Type 'debug on' to enable debug mode

Enter your query: find users with email domain @contractor.com in staging environment
Processing query...
2025-06-22T08:55:49.125Z [INFO] [pingone-mcp-server] Directly calling tool: list_pingone_users
Query processed successfully

╭─ Result ─╮
│ {       │
│   "users": [ │
│     {         │
│       "id": "user-uuid-here", │
│       "username": "jane.doe", │
│       "email": "jane.doe@contractor.com", │
│       "enabled": true, │
│       "type": "Contractor" │
│     }       │
│   ]         │
│ }           │
╰───────────╯

Enter your query: show me audit activity for authentication failures yesterday
Processing query...
2025-06-22T08:55:52.125Z [INFO] [pingone-mcp-server] Directly calling tool: create_date_range
2025-06-22T08:55:53.096Z [INFO] [pingone-mcp-server] Directly calling tool: get_pingone_environment_activity
Query processed successfully

╭─ Result ─╮
│ {       │
│   "activities": [ │
│     {         │
│       "action": {"type": "AUTHENTICATION"}, │
│       "result": {"status": "failed"}, │
│       "actors": {"user": "failed.user@company.com"}, │
│       "recordedAt": "2025-06-21T14:30:15Z" │
│     }       │
│   ]         │
│ }           │
╰───────────╯

⚠️ Good to Know

Production Ready 🚀

• Stable release with comprehensive tool coverage
• Full user lifecycle management capabilities
• Multi-environment support for Production/Staging/Development workflows
• Robust error handling and logging
• Tested with multiple AI providers
• Ready for enterprise environments

Security First 🛡️

• Designed for least-privilege operation
• Secure authentication with PingOne APIs
• Multi-environment isolation
• Comprehensive audit logging
• Tool call transparency and monitoring

Current Capabilities 🔍

• Complete user and group management operations
• Advanced SCIM filtering and search across populations
• Audit log analysis with natural language date ranges
• MFA device management and compliance checking
• Real-time tool call visibility
• Multiple transport protocols
• Rich client applications for testing
• Production-ready error handling

🗺️ Roadmap

v1.0.0 - Current

• Complete user management with SCIM filtering
• Group and population management
• MFA device management
• Audit log analysis with datetime tools
• Multi-environment support
• STDIO and HTTP transport support
• Tool call visibility and logging
• Advanced client applications
• Multiple AI provider support

Future Releases:

• Application management operations
• User provisioning and lifecycle workflows
• Advanced compliance reporting
• Authentication policy management
• Risk and sign-on policy tools
• Approval workflows for sensitive operations
• Role-based access control for MCP operations
• Bulk operations with automatic chunking

🆘 Need Help?

Before raising an issue, check:

1. 📝 Multi-environment configuration in .env file
2. 🔑 PingOne API permissions and credentials for each environment
3. 🔌 MCP client compatibility
4. 📊 Context window limits (70-90 users maximum)
5. 📊 Server logs for error details

Getting Support:

• 📚 Check the documentation above
• 🐛 Report bugs on GitHub
• 💡 Request features on GitHub

Common Issues:

• "Too many results": Use SCIM filters to limit user queries under 70-90 users
• "Environment not found": Run list_configured_environments first to see available environments
• "Invalid filter": Check tool documentation for supported SCIM filter attributes

💡 Feature Requests & Ideas

Have an idea or suggestion? Open a feature request on GitHub!

👥 Contributors

Interested in contributing? We'd love to have you! Open an issue or submit a pull request.

⚖️ Legal Stuff

Check out for the full license details.

🌟 © 2025 PingOne MCP Server. Made with ❤️ for the PingOne and AI communities.
